Flight track for flight leg

GET

/shipping/flights/track/for_flight_leg/v1/:flight_leg_id

GET

/shipping/flights/track/for_flight_leg/v1/:flight_leg_id

1 import { ChrtClient } from "@chrt-inc/typescript-sdk";
2
3 async function main() {
4     const client = new ChrtClient({
5         token: "YOUR_TOKEN_HERE",
6     });
7     await client.shipping.flights.getFlightTrackForFlightLegV1("flight_leg_id");
8 }
9 main();

1 {
2   "bearing": 87.5,
3   "cirium_flight_id": 1234567,
4   "heading": 85.3,
5   "legacy_route": "JFK DCT ALB DCT BDL DCT BOS",
6   "positions": [
7     {
8       "altitude_ft": 35000,
9       "date_utc": "2024-04-20T14:45:00Z",
10       "lat": 40.6413,
11       "lon": -73.7781,
12       "source": "ADS-B",
13       "speed_mph": 480
14     },
15     {
16       "altitude_ft": 36000,
17       "date_utc": "2024-04-20T15:00:00Z",
18       "lat": 41.2033,
19       "lon": -77.1945,
20       "source": "ADS-B",
21       "speed_mph": 485
22     }
23   ],
24   "waypoints": [
25     {
26       "lat": 40.6413,
27       "lon": -73.7781
28     },
29     {
30       "lat": 42.7469,
31       "lon": -73.8024
32     },
33     {
34       "lat": 41.9389,
35       "lon": -72.6832
36     }
37   ]
38 }

Returns the Cirium-sourced positional track for a flight leg — the live breadcrumb trail plus the planned path (waypoints + legacy route) in one read-through call, cached on read. | authz_personas=[driver_for_executor, coordinator_org_operators, executor_org_operators, order_executor_org_operators, shipper_org_operators] | () -> (FlightTrackRes)

Authentication

AuthorizationBearer

Bearer authentication of the form Bearer <token>, where token is your auth token.

Path parameters

flight_leg_idstringRequired

Response

Successful Response

bearingdouble

cirium_flight_idinteger

headingdouble

legacy_routestring

positionslist of objects

waypointslist of objects

Errors

422

Flights Get Flight Track for Flight Leg V1request Unprocessable Entity Error
