Flight track

GET

/tracking/sessions/flight_track/v1

GET

/tracking/sessions/flight_track/v1

import { ChrtClient } from "@chrt-inc/typescript-sdk";
async function main() {
    const client = new ChrtClient({
        token: "YOUR_TOKEN_HERE",
    });
    await client.tracking.sessions.flightTrackV1({
        flight_leg_id: "flight_leg_id",
        session_id: "session_id",
    });
}
main();

{
  "actual_flight_path": [
    {
      "altitude_feet": 1,
      "ground_speed_knots": 1,
      "heading_degrees": 1,
      "latitude": 1.1,
      "longitude": 1.1,
      "name": "string",
      "position_source": "string",
      "received_at_timestamp": "2024-01-15T09:30:00Z"
    }
  ],
  "fa_flight_id": "string",
  "last_refresh_attempt_at_timestamp": "2024-01-15T09:30:00Z",
  "latest_position": {
    "altitude_feet": 1,
    "ground_speed_knots": 1,
    "heading_degrees": 1,
    "latitude": 1.1,
    "longitude": 1.1,
    "name": "string",
    "position_source": "string",
    "received_at_timestamp": "2024-01-15T09:30:00Z"
  },
  "planned_flight_path": [
    {
      "altitude_feet": 1,
      "ground_speed_knots": 1,
      "heading_degrees": 1,
      "latitude": 1.1,
      "longitude": 1.1,
      "name": "string",
      "position_source": "string",
      "received_at_timestamp": "2024-01-15T09:30:00Z"
    }
  ]
}

Returns the FlightAware actual path, planned path, and latest position for one of the session’s flight legs; pass force_refresh=true to bypass the cache. Access restricted to the caller’s organization or shared organizations. | auth: api_key | authz: min_org_role=operator | () -> (FlightTrackRes)

Authentication

AuthorizationBearer

Bearer authentication of the form Bearer <token>, where token is your auth token.

Query parameters

session_idstringRequired

flight_leg_idstringRequired

force_refreshbooleanOptionalDefaults to false

Bypass the cache and fetch the latest flight track.

Response

Successful Response

actual_flight_pathlist of objectsOptional

fa_flight_idstring or nullOptional

last_refresh_attempt_at_timestampstring or nullOptionalformat: "date-time"

latest_positionobject or nullOptional

planned_flight_pathlist of objectsOptional

Errors

422

Unprocessable Entity Error
