chrt tracks shipments through a mix of driver location (the chrt mobile app reporting the driver’s GPS), flight data (FlightAware feeds), and tracker devices (Tive and similar hardware reporting independently of any phone). On any active order, all three streams can flow at once. This page is the model behind every map, timeline, and ETA badge in the product.

The two tracking surfaces

Surface	Driven by	Used for
On-order tracking	The driver app + flight integrations + any tracker linked to the cargo.	Watching a chrt order in flight: map, timeline, ETA, milestones, proof of delivery.
Standalone tracker session	A registered tracker device with no order attached.	Monitoring a shipment chrt isn’t dispatching — your own cargo, or a partner’s.

The two surfaces share the same underlying objects but are entered from different routes (/orders/<order-ref> versus /tracking/sessions/<id>).

Tracker session

A tracker session is a window of recording for a single tracker device. Sessions have a start time, an optional end time (or auto-termination after three days by default), a status (active or ended), and a stream of timestamped data points — latitude, longitude, battery, temperature when supported.

Surface	How a session is created
Standalone	Manually from chrt.com/tracking/devices or via the tracker API.
On-order	Automatically when a tracker device is linked to cargo on the order.

Each session can optionally be associated with one or more flights so chrt can alert you if the device’s location is inconsistent with the flight (for example, the device hasn’t reached the airport in time for boarding).

Milestones

Every task on a task group emits a milestone event when its state changes. The set of possible milestones depends on the task-group type:

Ground tasks — pickup, deliver, tender_to_airline, recover_from_airline, consolidate, hold, other.
Flight tasks (auto-completed from FlightAware) — cargo_received_by_airline, cargo_loaded_onto_flight, flight_departed, flight_arrived, cargo_offloaded_from_flight, cargo_cleared_customs, cargo_ready_for_recovery.
OBC tasks — the courier-and-cargo lifecycle from courier_departed_for_pickup_location through courier_arrived_at_delivery_location.

Milestones become entries on the order timeline (the Details tab on the order page) and trigger any matching email or webhook notifications. See Orders, task groups, segments, stops for the full task model.

ETA

The ETA for each upcoming task on an order is calculated live and shown on the order timeline and on stop event panels. The calculation differs for ground-only orders versus orders that include a flight.

Ground-only orders

For each task in order, chained:

ETA(task[0])     = staged_at_timestamp + 2 hours          (live)
                   = now + 1 hour                          (draft preview)
ETA(task[n])     = ETA(task[n-1]) + drivingDuration + 20 min buffer

drivingDuration comes from the Mapbox Directions API; the buffer is 20 minutes between consecutive tasks. If a task group is in progress and a driver location is known, the next ETA is recalculated from the driver’s current position via Mapbox routing.

Orders with flight task groups

Flight legs override the chain at their boundary:

Task	ETA
`tender_to_airline`	Flight departure time − 2 hours.
`recover_from_airline`	Flight arrival time.
Tasks after `recover_from_airline`	Previous ETA + drivingDuration + 30-minute buffer (longer than the ground default to account for offload and customs).

Flight departure and arrival times pull from FlightAware in this priority:

Departure — actual_out > estimated_out > scheduled_out.
Arrival — actual_in > estimated_in > predicted_in > scheduled_in.

Time windows override ETA

Every task can have a time window with left_boundary_timestamp (earliest acceptable) and right_boundary_timestamp (latest acceptable). When a time window is set, ETA prefers right_boundary_timestamp (the deadline) over the routed estimate, and uses the latest of multiple overlapping windows.

Constants

Constant	Value
First task buffer (live)	2 hours after stage
First task buffer (draft preview)	1 hour after now
Default buffer between tasks	20 minutes
Post-recover buffer	30 minutes
Default driving duration fallback	30 minutes (when Mapbox routing fails)
Flight pre-departure tender buffer	2 hours

Public links

A public tracking link is a chrt-hosted page anyone can open with just the URL — no chrt account required. Two flavors:

Public link kind	URL pattern	What it shows
Order public page	`https://chrt.com/orders/public/<order-ref>`	A stripped-down view of an order: planned route, current driver position, milestone timeline. The order owner controls which segments / map layers are visible.
Session public page	`https://chrt.com/tracking/sessions/public/<session-id>`	The current and historical position of one tracker session, with an optional “See History” pane.

Public links are revocable at any time. The on-order public link uses a share dialog with per-segment toggles; the standalone-session public link is created from the session detail page.

See Public tracking links (shippers) and Share a tracking session for the share flows.

Map layers

The Map tab on an order page can show three layers simultaneously:

Layer	Source
Task group by driver	Driver phone location, one path per task group.
Cargo by driver	Cargo position inferred from the driver carrying it.
Cargo by device	Independent tracker device pings, when a device is linked to cargo.

Use the layer toggle in the top-left of the map to switch between them.

Orders, task groups, segments, stops — the task and milestone model.
Tracking shipments (shippers) — reading the order page as a shipper.
Public tracking links (shippers) — sharing on-order tracking.
Standalone trackers — creating sessions for your own cargo.
Tracker API — programmatic access to sessions and data points.
Trackers on orders — attaching devices to cargo on a chrt order.
