Create

POST

/tracking_integrations/reelables/assets/create/v1

POST

/tracking_integrations/reelables/assets/create/v1

1 import { ChrtClient } from "@chrt-inc/typescript-sdk";
2
3 async function main() {
4     const client = new ChrtClient({
5         token: "YOUR_TOKEN_HERE",
6     });
7     await client.trackingIntegrations.reelables.assets.createV1({
8         name: "name",
9         nfc_id: "nfc_id",
10         schema_version: 1,
11     });
12 }
13 main();

1 {
2   "_id": "_id",
3   "asset_id": "asset_id",
4   "name": "name",
5   "org_id": "org_id",
6   "schema_version": 1,
7   "workspace_id": "workspace_id",
8   "created_at_timestamp": "2024-01-15T09:30:00Z",
9   "destination_geofence_location": {
10     "geometry": {
11       "type": "GeometryCollection",
12       "geometries": [
13         {
14           "type": "LineString",
15           "coordinates": [
16             []
17           ]
18         }
19       ]
20     },
21     "type": "Feature",
22     "bbox": [
23       {
24         "key": "value"
25       }
26     ],
27     "id": 1,
28     "properties": {
29       "address": "address",
30       "name": "name"
31     }
32   },
33   "destination_geofence_radius_miles": 1.1,
34   "label": {
35     "added_at_timestamp": "2024-01-15T09:30:00Z",
36     "ble_id": 1,
37     "nfc_id": "nfc_id",
38     "config__reporting_interval": "config__reporting_interval"
39   },
40   "last_seen_at_location": {
41     "geometry": {
42       "type": "GeometryCollection",
43       "geometries": [
44         {
45           "type": "LineString",
46           "coordinates": [
47             []
48           ]
49         }
50       ]
51     },
52     "type": "Feature",
53     "bbox": [
54       {
55         "key": "value"
56       }
57     ],
58     "id": 1,
59     "properties": {
60       "address": "address",
61       "name": "name"
62     }
63   },
64   "last_seen_at_location_city": "last_seen_at_location_city",
65   "last_seen_at_location_large_city": "last_seen_at_location_large_city",
66   "last_seen_at_timestamp": "2024-01-15T09:30:00Z",
67   "synced_at_timestamp": "2024-01-15T09:30:00Z"
68 }

Creates and links a labeled Reelables asset for the caller’s organization. | authz: min_org_role=operator | (ReelablesAssetClientCreate1) -> (ReelablesAsset1)

Authentication

AuthorizationBearer

Bearer authentication of the form Bearer <token>, where token is your auth token.

Request

This endpoint expects an object.

namestringRequiredformat: "^[a-zA-Z0-9!@#$&()\-`.+,/" ]*$"1-500 characters

nfc_idstringRequiredformat: "^[a-zA-Z0-9]*$"1-20 characters

schema_versionintegerRequired

Response

Successful Response

_idstring

asset_idstring

namestring

org_idstring

Must be a string starting with org_

schema_versioninteger

workspace_idstring

created_at_timestampdatetimeOptional

destination_geofence_locationobjectOptional

GeoJSON Feature with typed properties for locations

The geometry field is strongly typed as Geometry (union of all geometry types) but remains optional to match the base Feature class specification. To ensure geometry is always present, validate it at runtime or make it required.

destination_geofence_radius_milesdoubleOptional<=10000Defaults to 0.1

labelobjectOptional

last_seen_at_locationobjectOptional

GeoJSON Feature with typed properties for locations

last_seen_at_location_citystringOptional

last_seen_at_location_large_citystringOptional

last_seen_at_timestampdatetimeOptional

synced_at_timestampdatetimeOptional

Errors

422

Assets Create V1request Unprocessable Entity Error
